ABS210 Bridge Rectifier - DO-214AC (SMA) SMD Package

The ABS210 is a single-phase bridge rectifier in a compact DO-214AC (SMA) SMD package, designed for efficient conversion of AC input into DC output. It integrates four diodes in a full-bridge configuration, ensuring reliable rectification with high surge current capability and low forward voltage drop. With its space-saving design and strong electrical performance, the ABS210 is widely used in adapters, LED drivers, battery chargers, and switch-mode power supplies (SMPS).

Features of ABS210 Bridge Rectifier:

1. Single-phase full-wave bridge rectifier for AC to DC conversion
2. Compact DO-214AC (SMA) SMD package for space-saving PCB layouts
3. Reverse voltage capability up to 1000V
4. Forward average current up to 2A
5. High peak surge current capability for reliable startup
6. Low forward voltage drop for improved efficiency
7. Suitable for power adapters, LED drivers, and SMPS circuits
8. RoHS compliant and optimized for automated SMD assembly

Specifications of ABS210:

• Model: ABS210
• Type: Bridge Rectifier
• Peak Repetitive Reverse Voltage: 1000V
• Average Forward Current: 2A
• Peak Forward Surge Current: 50A
• Forward Voltage Drop: 1.1V (typical)
• Package: DO-214AC (SMA) â€?SMD
• Operating Temperature Range: -55°C to +150°C

Package Includes:

1 × ABS210 Bridge Rectifier â€?DO-214AC (SMA) SMD Package
