1S 5A NMC Battery Protection Module

 This is a 1S protection module bms for the NMC (Lithium Manganese Cobalt Oxide) batteries. This board has the following protective functions from: over-charge, over-discharge, over-current, over-temperature and short-circuit. It is designed to protect lithium-ion/polymer battery for one-cell lithium-ion/polymer battery powered systems, such as cellular phones.

This BMS (Battery Management System) charge-discharge controller module comes with pre-soldered nickel strip ready to use for a single NMC cell such as . The maximum allowable current is 5A. If the maximum permissible value of the supply voltage is exceeded, the charge controller activates the “protectionâ€?mode.

Product Description of NMC battery Protection Module 1S 5Amps

Features of NMC battery Protection Module 1S 5Amps

• Pre-soldered Nickel Strip ready to mount on battery
• Small size designed for a four-cell battery pack
• Can be applied to various 3.7V lithium core
• Easy and convenient connection circuit
• Protection against over-charge and over-discharge
• IC components: DW01 + 8205A
• Size: approx.35.2 (L) x 7.3 (W) x 1.7 mm (H)
• Low standby current consumption

Technical Specifications of NMC battery Protection Module 1S 5Amps

Additional Resources

• DW01 and 8205A (ICs used in the module)
